60NCS-3-1-18

SEVERE DUTY Elektrim Premium 230/460V 60N Series TEFC IP55 1800RPM cast iron foot mounted electric motor features up to 1.4 service factor, oversized ball bearings, VPI, and VFD 10:1CT & 20:1VT.

Product Group

Severe Duty

Horsepower

1

Nominal Speed

1765

Phase

3

Voltage

208-230/460V 60Hz, 190/380V 50Hz

Frame

143TC

Frame Material

Cast Iron

Flange Type

-

Feet

YES

Bearings

6205 2Z (DE), 6205 2Z (ODE)

Mounting Position

F1

Enclosure

TEFC

20NCM-3-1-18

Elektrim Premium 20N Series TEFC IP55 1800RPM cast iron C-Face electric motor features a high 1.4 service factor, oversized ball bearings, VPI, VFD 10:1CT & 20:1VT and is rerateable for multiple voltages.

Product Group

Premium Efficient

Horsepower

1

Nominal Speed

1765

Phase

3

Voltage

208-230/460V 60Hz, 190/380V 50Hz

Frame

143TC

Frame Material

Cast Iron

Flange Type

-

Feet

YES

Bearings

6205 2Z (DE), 6205 2Z (ODE)

Mounting Position

F1

Enclosure

TEFC

20MDM-3-20-18P/R

Elektrim PREMIUM Efficiency IE3 Metric IEC electric motor, TEFC IP55 1800/1500RPM cast iron REDUCED D-flange with feet mounted (B35 Reduced) Design H, oversized ball bearings, VPI for best electrical performance, rated 60/50Hz equipped with 12 separate le

Product Group

Metric IEC Motors

Horsepower

20

Nominal Speed

1775

Phase

3

Voltage

230/460V 60Hz, 380V/400V 50Hz

Frame

160L

Frame Material

Cast Iron

Flange Type

B35 (Reduction D-Flange)

Feet

YES

Bearings

6309 2Z C3 (DE), 6309 2Z C3 (ODE)

Mounting Position

F3

Enclosure

TEFC
